Timing Chain Kit
59768Set
| Quality | iwis original OEM quality, Made in Germany |
| Supplementary Article/Supplementary Info: | with slide rails,with chain tensioner,with camshaft adjuster,with camshaft gear,with crankshaft gear,with sleeve,with crankshaft seal,Check and replace gears if necessary |
| Supplementary Article/Info 2: | with control housing gasket,with bolts/screws |
| Number of chain links: | 130 |
| Guarantee: | 5 years guarantee or up to 100,000 km |
| Chain Type: | Silent Chain,Closed chain |
| Unit | 1 |
| Manufacturer | Model | Motorcode | Built from | to | K-type | KW |
|---|---|---|---|---|---|---|
| SKODA | FABIA II Combi (545) | BTS, CFNA | 10/2007 | 12/2014 | 23167 | 0077 |
| SKODA | OCTAVIA II (1Z3) | BLF | 02/2004 | 10/2008 | 17974 | 0085 |
| SKODA | OCTAVIA II Combi (1Z5) | BLF | 02/2004 | 10/2008 | 18247 | 0085 |
| SKODA | ROOMSTER (5J7) | BTS, CFNA | 09/2006 | 05/2015 | 19275 | 0077 |
| SKODA | SUPERB II (3T4) | CAXC | 07/2008 | 05/2015 | 28252 | 0092 |
| SKODA | SUPERB II Kombi (3T5) | CAXC | 10/2009 | 05/2015 | 32783 | 0092 |
| SKODA | RAPID (NH3, NK3, NK6) | 07/2012 | 06/2015 | 59064 | 0077 | |
| SKODA | RAPID Spaceback (NH1) | 07/2012 | 06/2015 | 105755 | 0077 | |
| SKODA | ROOMSTER (5J7) | 06/2006 | 07/2010 | 133133 | 0077 | |
| SKODA | FABIA II (542) | BTS, CFNA , CLSA | 04/2007 | 12/2014 | 22947 | 0077 |
| VW | PASSAT B6 (3C2) | CAXA | 05/2007 | 07/2010 | 27544 | 0090 |
| VW | PASSAT B6 (3C2) | BLF | 03/2005 | 06/2008 | 18520 | 0085 |
| VW | PASSAT B6 Estate (3C5) | CAXA | 05/2007 | 11/2010 | 27540 | 0090 |
| VW | PASSAT B6 Estate (3C5) | BLF | 08/2005 | 06/2008 | 18726 | 0085 |
| VW | POLO IV (9N_, 9A_) | BTS | 05/2006 | 11/2009 | 19698 | 0077 |
| VW | TOURAN (1T1, 1T2) | BLG, CAVB | 11/2006 | 05/2010 | 27994 | 0125 |
| VW | TOURAN (1T1, 1T2) | BLP, BLF , BAG | 02/2003 | 01/2007 | 17174 | 0085 |
| VW | EOS (1F7, 1F8) | BLF | 06/2006 | 05/2008 | 18971 | 0085 |
| VW | JETTA IV (162, 163, AV3, AV2) | 12/2011 | 04/2018 | 57357 | 0077 | |
| VW | GOLF V (1K1) | BKG, BLN | 10/2003 | 07/2006 | 17743 | 0066 |
| VW | GOLF V (1K1) | CAXA | 05/2007 | 11/2008 | 23162 | 0090 |
| VW | GOLF V (1K1) | BAG, BLF , BLP | 10/2003 | 07/2008 | 17645 | 0085 |
| VW | GOLF V Estate (1K5) | CAXA | 06/2007 | 07/2009 | 23163 | 0090 |
| VW | GOLF PLUS V (5M1, 521) | BLN | 07/2005 | 11/2006 | 22557 | 0066 |
| VW | GOLF PLUS V (5M1, 521) | CAXA | 06/2007 | 12/2013 | 23164 | 0090 |
| VW | GOLF PLUS V (5M1, 521) | BLF | 12/2004 | 05/2008 | 18391 | 0085 |
| VW | JETTA III (1K2) | CAXA | 05/2007 | 10/2010 | 23295 | 0090 |
| AUDI | A3 (8P1) | CAXC, CMSA | 09/2007 | 08/2012 | 26581 | 0092 |
| SEAT | ALTEA XL (5P5, 5P8) | CAXC | 11/2007 | 07/2015 | 24241 | 0092 |
| SEAT | IBIZA Mk IV (6J5, 6P1) | BTS | 05/2008 | 03/2012 | 31112 | 0077 |
| SEAT | IBIZA Mk IV SC (6J1, 6P5) | BTS | 07/2008 | 05/2015 | 31113 | 0077 |
| SEAT | LEON (1P1) | CAXC | 11/2007 | 12/2012 | 28173 | 0092 |
| SEAT | TOLEDO III (5P2) | CAXC | 11/2007 | 05/2009 | 122653 | 0092 |
| SEAT | ALTEA (5P1) | CAXC | 11/2007 | 07/2015 | 24240 | 0092 |
| SEAT | IBIZA Mk IV ST (6J8, 6P8) | 02/2012 | 05/2015 | 119216 | 0077 |
| Manufacturer | Comparison number |
|---|---|
| SEAT | 038 103 085E |
| SKODA | 038 103 085E |
| VW | 038 103 085E |
| VAG | 038 103 085E |
| AUDI | 038 103 085E |
| SEAT | 03C 103 825A |
| SKODA | 03C 103 825A |
| VW | 03C 103 825A |
| VAG | 03C 103 825A |
| AUDI | 03C 103 825A |
| SEAT | 03C 105 209BE |
| SKODA | 03C 105 209BE |
| VW | 03C 105 209BE |
| VAG | 03C 105 209BE |
| AUDI | 03C 105 209BE |
| SEAT | 03C 109 088E |
| SKODA | 03C 109 088E |
| VW | 03C 109 088E |
| VAG | 03C 109 088E |
| AUDI | 03C 109 088E |
| SEAT | 03C 109 158A |
| SKODA | 03C 109 158A |
| VW | 03C 109 158A |
| VAG | 03C 109 158A |
| AUDI | 03C 109 158A |
| SEAT | 03C 109 287G |
| SKODA | 03C 109 287G |
| VW | 03C 109 287G |
| VAG | 03C 109 287G |
| AUDI | 03C 109 287G |
| SEAT | 03C 109 293 |
| SKODA | 03C 109 293 |
| VW | 03C 109 293 |
| VAG | 03C 109 293 |
| AUDI | 03C 109 293 |
| SEAT | 03C 109 469K |
| SKODA | 03C 109 469K |
| VW | 03C 109 469K |
| VAG | 03C 109 469K |
| AUDI | 03C 109 469K |
| SEAT | 03C 109 507AH |
| SKODA | 03C 109 507AH |
| VW | 03C 109 507AH |
| VAG | 03C 109 507AH |
| AUDI | 03C 109 507AH |
| SEAT | 03C 109 509P |
| SKODA | 03C 109 509P |
| VW | 03C 109 509P |
| VAG | 03C 109 509P |
| AUDI | 03C 109 509P |
| SEAT | 03C 109 571F |
| SKODA | 03C 109 571F |
| VW | 03C 109 571F |
| VAG | 03C 109 571F |
| AUDI | 03C 109 571F |
| SEAT | 03E 109 511 |
| SKODA | 03E 109 511 |
| VW | 03E 109 511 |
| VAG | 03E 109 511 |
| AUDI | 03E 109 511 |
| SEAT | D 176 501 A1 |
| SKODA | D 176 501 A1 |
| VW | D 176 501 A1 |
| VAG | D 176 501 A1 |
| AUDI | D 176 501 A1 |
| SEAT | N 902 562 02 |
| SKODA | N 902 562 02 |
| VW | N 902 562 02 |
| VAG | N 902 562 02 |
| AUDI | N 902 562 02 |
| SEAT | N 910 486 01 |
| SKODA | N 910 486 01 |
| VW | N 910 486 01 |
| VAG | N 910 486 01 |
| AUDI | N 910 486 01 |
| SEAT | N 910 972 01 |
| SKODA | N 910 972 01 |
| VW | N 910 972 01 |
| VAG | N 910 972 01 |
| AUDI | N 910 972 01 |
| SEAT | N 911 970 01 |
| SKODA | N 911 970 01 |
| VW | N 911 970 01 |
| VAG | N 911 970 01 |
| AUDI | N 911 970 01 |
| Description | Article number | OE comparison number | Amount |
|---|---|---|---|
| Timing Chain | 59182 | 1 | |
| Guides, timing chain | 59251 | 1 | |
| Guides, timing chain | 59253 | 1 | |
| Tensioner, timing chain | 59285 | 1 | |
| Gasket, timing case | 59323 | 1 | |
| Seal Ring | 59328 | 2 | |
| Screw, camshaft gear | 59340 | 1 | |
| Gear, camshaft | 59774 | 1 | |
| Gear, crankshaft | 59778 | 1 | |
| Camshaft Adjuster | 59780 | 03C 109 088E | 1 |
| Bolt, crankshaft gear | 59783 | 1 | |
| Sliding Rail Bolts, timing chain | 59785 | 4 | |
| Screw | 59790 | 2 | |
| Screw | 59791 | 1 | |
| Sleeve | 59792 | 1 | |
| Shaft Seal, crankshaft | 59795 | 1 |
